Specifications:

• Camera
• Image Sensor3K CMOS
• Max. Resolution2960 (H) × 1664 (V)
• Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter TimePAL: 1/30 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0° to 360°,Tilt: 0° to 180°,Rotate: 0° to 360°
• Signal SystemPAL/NTSC

• Lens
• Lens Type2.8 mm, 3.6 mm fixed lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 105.0°, vertical FOV: 62.5°, diagonal FOV: 129°;

  3.6 mm, horizontal FOV: 90.0°, vertical FOV: 50.2°, diagonal FOV: 109°

• Lens MountM12

• Microphone
• Pickup DistanceIn a radius of up to 5 m
• Amount1

• Speaker
• Rated Power2 W
• Speaker RangeIn a radius of up to 5 m

• Illuminator
• Supplement Light TypeSmart,IR,White Light
• Supplement Light RangeIR: Up to 40 m,White Light: Up to 40 m

• Image
• Image Settings

  Anti-banding,

  Brightness,

  Sharpness,

  Smart IR

• Frame RateTVI: 3K @10 fps/12.5 fps/20 fps/25 fps, 4 MP @25 fps/30 fps, 1080P @25 fps/30 fps
• Day/Night ModeAuto/Color
• Wide Dynamic Range (WDR)Digital WDR
• Image Enhancement

  DWDR,

  BLC,

  HLC,

  Global

• Noise Reduction3D DNR
• White Balance

  Auto,

  Manual

• Audio
• Audio FunctionEcho Cancellation, AI Noise Reduction, Automatic Gain Control

• Interface
• Video Output1 HD analog output
• AlarmFlashing Light Alarm (Red & Blue)

• General
• Power

  12 VDC ± 25%, max.7 W,

  *You are recommended to use one power adapter to supply the power for one camera. If a high-impedance cable is used (such as the 18 m extension cable in the kit package), a 15 VDC adapter is required.

• MaterialMain body: Plastic; Front cover: Metal
• Dimension211 mm × 83.5 mm × 80.7 mm (8.3" × 3.3" × 3.2")
• Approx. 440 g (1.0 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish

• Approval
• ProtectionIP67
