Specifications:

• External interface
• Network interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
• USB interfaceRear panel: 2 × USB 2.0

• Video/Audio input/output
• Video inputHDTVI, AHD, CVI, CVBS, IP

• Recording
• Encoding resolution

  When 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF

  When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF

• Frame rate

  Main stream:

  When 1080p lite mode enabled:

  1080p lite/HD 720p lite/WD1/4CIF/VGA@12fps; CIF@25fps(P)/30fps(N)

  When 1080p lite mode not enabled:

  For 720p stream access:

  720p/WD1/4CIF/VGA@12fps; CIF@25fps(P)/30fps(N)

  For SD stream access:

  WD1/4CIF/VGA/CIF@25fps(P)/30fps(N)

  Sub-stream:

  CIF/QVGA/QCIF@25fps(P)/30fps(N)

• Audio compressionG.711u

• Video and Audio
• IP video input

  2-ch (up to 10-ch)

  Up to 5 MP

  H.264+/H.264

• Analog video input

  8-ch

  BNC interface (1.0 Vp-p, 75 Ω)

• Audio input1-ch
• Two-way audioRCA (2.0 Vp-p, 1 KΩ)
• VGA/HDMI output

  1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

  HDMI and VGA simultaneous output

• Auxiliary interface
• SATA1 SATA interface
• CapacityUp to 6 TB capacity for each disk

• Camera
• Lens70.9°, 3.6 mm
• Image Sensor1MP CMOS image sensor

• General
• Operating Condition

  DVR：

  -10 °C to 55 °C (14 °F to 131 °F), Humidity: 10% to 90%

  Camera：

  -40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)

• Power ConsumptionMax. 4 W
• Protection Level

  DS-2CE16C0T-IRP

  IP66

  DS-2CE56C0T-IR

  IP66

• IR RangeUp to 20 m
• Dimensions

  DVR：

  263(W) × 227(D) × 48(H) mm (10.4 × 8.9 × 1.9 inch)

• ≤ 6.2 kg (13.7 lb)
