Specifications:

• External interface
• Network interface1×100Mbps
• USB interfaceRear panel: 2 × USB 2.0

• Video/Audio input/output
• Video inputHDTVI, AHD, CVI, CVBS, IP

• Recording
• Encoding resolution

  When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF

  When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF

• Frame rateMain stream: When 1080p Lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps(P)/30fps(N) When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps(P)/30fps(N) Sub-stream: 2CIF@6fps; CIF/QVGA/QCIF@25fps(P)/30fps(N)
• Audio compressionG.711u

• Video and Audio
• IP video input

  1-ch (up to 5-ch)

  Up to 1080p resolution

  H.264+/H.264

• Analog video input

  4-ch

  BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

• Audio input1-ch, RCA (2.0 Vp-p, 1 KΩ)
• Two-way audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
• VGA/HDMI output1-ch, 1920 × 1080/60 Hz,1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz HDMI and VGA simultaneous output

• Auxiliary interface
• SATA1 SATA interface
• CapacityUp to 6 TB capacity for each disk

• Camera
• Lens70.9°, 3.6 mm
• Image Sensor1 MP CMOS image sensor

• General
• Operating Condition

  DS-2CE16C0T-IRP:-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

  DS-2CE56C0T-IR:-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

  DVR: -10 °C to 55 °C (14 °F to 131 °F), Humidity: 10% to 90%

• Power ConsumptionMax. 4 W
• Protection LevelDS-2CE16C0T-IRP: IP66
• IR RangeUp to 20m
• Dimensions

  DS-2CE16C0T-IRP: Φ70 × 149.5 mm (Φ2.76 × 5.89 inch)

  DS-2CE56C0T-IR:Φ89.5 × 69.8 mm (Φ3.52 × 2.75 inch)

  DVR: 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)

• DS-2CE16C0T-IRP: 300 g (0.66 lb)

  DS-2CE56C0T-IR:280 g(0.62lb)

  DVR: ≤ 1 kg (2.2 lb)

  kit: ≤ 3.1 kg (6.9 lb)
