Specifications:

• Camera
• Image Sensor1/2.7" Progressive Scan CMOS
• Max. Resolution2560 × 1440
• Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
• Shutter Time1/3 s to 1/100,000 s
• Day & NightIR cut filter
• Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

• Lens
• Lens TypeFixed focal lens, 2.8, 4, and 6 mm optional
• Focal Length & FOV

  2.8 mm, horizontal FOV 94°, vertical FOV 49°, diagonal FOV 114°

  4 mm, horizontal FOV 70°, vertical FOV 35°, diagonal FOV 85°

  6 mm, horizontal FOV 46°, vertical FOV 24°, diagonal FOV 54°

• ApertureF1.6
• Iris TypeFixed
• Lens MountM12
• Depth of Field

  2.8 mm: 1.3 m to ∞

  4 mm: 2 m to ∞

  6 mm: 4.1 m~44 m

• DORI
• DORI

  4 mm, D: 68 m, O: 27 m, R: 13 m

  4 mm, D: 100 m, O: 39 m, R: 20 m, I: 10 m

  6 mm, D: 142 m, O: 56 m, R: 28 m, I: 14 m

• Illuminator
• Supplement Light TypeIR, White Light
• IR Wavelength850 nm
• Supplement Light RangeUp to 30 m
• Smart Supplement LightYes

• Video
• Main Stream

  50 Hz: 20 fps (2560 x 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 20 fps (2560 x 1440, 1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 20 fps (768 × 432)

  60 Hz: 20 fps (768 × 432)

• Video Compression

  Main stream: H.265/H.264,

  Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 8 Mbps
• H.264 TypeBaseline Profile,Main Profile,High Profile
• H.265 TypeMain Profile
• Bit Rate ControlCBR,VBR
• Region of Interest (ROI)1 fixed region for main stream

• Audio
• Audio TypeMono sound
• Audio CompressionG.711(ulaw)/ (AAC-LC)
• Audio Bit Rate64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
• Audio Sampling Rate8 kHz/16 kHz
• Environment Noise FilteringYes

• Network
• SecurityPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
• Simultaneous Live ViewUp to 6 channels
• APIONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
• ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, UPnP
• User/Host

  Up to 32 users

  3 user levels: administrator, operator, and user

• Client

  Wired network: Hik-Connect, iVMS-4200

  Wi-Fi: iVMS-4200

  *Wi-Fi connection with Hik-Connect directly is not possible

• Web BrowserLocal service: IE 11, Chrome 57.0+, Firefox 52.0+, Edge 89+

• Wi-Fi
• Wi-Fi ProtocolIEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.11ax
• Frequency Range2.4 GHz to 2.4835 GHz
• Channel Bandwidth20/40 MHz
• Modulation

  802.11n: QPSK, BPSK,16QAM, 64QAM,

  802.11b: CCK, QPSK, BPSK,

  802.11g: QPSK, BPSK,16QAM, 64QAM

• Transfer Rate11n: up to 300 Mbps

• Image
• Image Parameters SwitchYes
• Wide Dynamic Range (WDR)Digital WDR
• SNR≥ 52 dB
• Day/Night SwitchDay, Night, Auto, Schedule
• Image EnhancementBLC, HLC, 3D DNR
• Image SettingsSaturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
• Privacy Mask4 programmable polygon privacy masks

• Interface
• On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Built-in MicrophoneYes
• Built-in SpeakerYes
• Reset KeyYes
• Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port

• Event
• Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),exception
• LinkageNotify surveillance center, send email, trigger recording, trigger capture, audible warning

• General
• Power12 VDC ± 25%, 0.55 A, max. 6.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,A switching adapter is included in the package.
• MaterialBase: plastic, front cover: metal, back cover: plastic
• Dimension260.9 mm × 113.9 mm × 67.4 mm (10.3" × 4.5" × 2.7")
• Package Dimension300 mm × 130 mm × 100 mm (10.2" × 5.1" × 4.9")
• Approx. 310 g (0.68 lb.)
• With Package WeightApprox. 550 g (1.21 lb.)
• Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• LanguageEnglish, Ukrainian
• General FunctionHeartbeat, anti-banding, mirror, password protection

• Approval
• EMCCE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
• RFCE-RED: EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1 (BT or 2.4G); EN 300328 V2.1.1 (BT or 2.4G); EN 62311:2008 (BT or 2.4G)
• Safety

  CB: IEC 62368-1: 2014+A11,

  CE-LVD: EN 62368-1: 2014/A11: 2017

• Environment

  CE-RoHS: 2011/65/EU,

  WEEE: 2012/19/EU,

  Reach: Regulation (EC) No 1907/2006

• ProtectionIP66: IEC 60529-2013
