Specifications:

• Camera
• Image Sensor1/2.7" Progressive Scan CMOS
• Max. Resolution2560 × 1440
• Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON), B/W: 0.005Lux @(F2.0, AGC ON), 0 Lux with IR

• Lens
• Focal Length2.8 mm;4 mm
• FOVHorizontal field of view: 91.1°, vertical field of view: 47.9°, diagonal field of view: 110.8°;Horizontal field of view: 69.9°, vertical field of view: 34.9°, diagonal field of view: 84.9°
• ApertureF2.0;F1.6

• Illuminator
• Supplement Light TypeIR,White Light
• Supplement Light RangeIR distance: up to 20 m,White light distance: up to 15 m
• IR Wavelength850 nm

• PTZ
• Movement Range (Pan)0° to 350°
• Movement Range (Tilt)0° to 75°
• Pan SpeedUp to 20°/s
• Tilt SpeedUp to 10°/s

• Video
• Main Stream

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (768 x 432)

  60 Hz: 30 fps (768 x 432)

• Video CompressionH.265, H.264, MJPEG
• Video Bit Rate32 Kbps to 8 Mbps
• H.264 TypeBaseline Profile/Main Profile/High Profile
• H.265 TypeMain Profile

• Audio
• Audio CompressionG.711ulaw/AAC-LC
• Audio Bit RateAAC-LC: 16 Kbps, 32 Kbps, 64 Kbps; G.711ulaw: 64 Kbps
• Audio Sampling Rate8 kHz/16 kHz
• Environment Noise FilteringYes

• Network
• ProtocolsIPv4,IPv6,HTTP,QoS,SMTP,NTP,RTSP,RTP,RTCP,TCP/IP,UDP,DHCP,Bonjour
• APIONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,Hik-Connect
• User/HostUp to 32 users. 3 user levels: administrator, operator, and user
• SecurityPassword protection,complicated password,watermark,WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,security audit log,host authentication (MAC address),basic and digest authentication for HTTP/HTTPS
• ClientWired network: Hik-Connect, iVMS-4200 Wi-Fi: iVMS-4200 *Wi-Fi connection with Hik-Connect directly is not possible

• Wireless (Wi-Fi)
• Wi-Fi ProtocolsIEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.11ax
• Frequency Range2.4 GHz to 2.4835 GHz
• Channel Bandwidth20/40 MHz
• Modulation

  802.11b: DBPSK, DQPSK, CCK,

  802.11g: BPSK, QPSK, 16QAM, 64QAM,

  802.11n: BPSK, QPSK, 16QAM, 64QAM,

  802.11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM

• Transfer Rate11b: up to 11 Mbps,11n: up to 150 Mbps,11g: up to 54 Mbps,11ax: up to 114 Mbps

• Image
• Image SettingsSaturation, brightness, contrast, and sharpness adjustable by client software or web browser
• Wide Dynamic Range (WDR)Digital WDR
• Image EnhancementBLC, HLC, 3D DNR
• Privacy Mask4 programmable polygon privacy masks

• Interface
• Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
• Built-in Microphone1 built-in microphone
• On-board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Built-in Speaker1 built-in speaker

• Event
• Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• LinkageNotify surveillance center,send email,trigger recording,trigger capture,audible warning

• Approval
• ProtectionIP54

• General
• Power12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug
• DimensionØ124 mm × 119 mm (Ø4.89" × 4.68")

• Weight:Approx. 290 g (0.6 lb.)

  With Package Weight:Approx. 390 g (0.8 lb.)

• MaterialPlastic
• Operating Condition-10 °C to 40 °C (-14 °F to 104 °F). Humidity 90% or less (non-condensing)
• General FunctionHeartbeat,anti-banding,mirror,password protection,password reset via email
• LanguageEnglish, Ukrainian
