Specifications:

• Camera
• Image Sensor1/3" Progressive Scan CMOS
• Max. Resolution2560 × 1440
• Min. IlluminationColor: 0.005 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
• Shutter Time1 s to 1/100,000 s
• Day & NightIR cut filter

• Lens
• Lens TypeFixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV

  2.8 mm, horizontal FOV 95.7°, vertical FOV 51.7°, diagonal FOV 113.7°

  4 mm, horizontal FOV 79.6°, vertical FOV 43.2°, diagonal FOV 93.2°

• Lens MountM12
• Iris TypeFixed
• ApertureF1.28

• PTZ
• Movement Range (Pan)0° to 340°
• Movement Range (Tilt)0° to 80°
• Pan SpeedUp to 20°/s
• Tilt SpeedUp to 25°/s

• DORI
• DORI

  2.8 mm D: 63.9 m, O: 25.4 m, R: 12.8 m, I: 6.4 m

  4 mm D: 77.6 m, O:30.8 m, R: 15.5 m, I: 7.8 m

• Illuminator
• Supplement Light TypeIR,White Light
• Supplement Light RangeUp to 30 m
• Smart Supplement LightYes
• IR Wavelength850 nm

• Video
• Main Stream

  50 Hz: 12.5 fps {2560 x 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 15 fps (2560 x 1440, 1920 × 1080, 1280 × 720)

• Video Bit Rate32 Kbps to 8 Mbps
• H.265 TypeMain Profile
• Bit Rate ControlCBR,VBR

• Audio
• Audio CompressionG.711ulaw
• Audio Bit Rate64 Kbps(G.711ulaw）
• Audio Sampling Rate8 kHz/16 kHz
• Environment Noise FilteringYes

• Network
• Simultaneous Live ViewUp to 6 channels
• APIISAPI
• User/Host

  Up to 32 users

  3 user levels: administrator, operator, and user

• ClientHik-Connect

• Mobile Communication
• StandardLTE-FDD,LTE-TDD,UMTS
• Frequency

  EU:LTE-FDD: B1/3/5/7/8/20/28

  LA:LTE-FDD: B2/3/4/5/7/8/28/66

• Uplink and Downlink Data RateEU: Cat 1, uplink: 5.1 Mbps, downlink: 10.3 Mbps, IN: Cat 1, uplink: 5.1 Mbps, downlink: 10.3 Mbps, LA: Cat 1, uplink: 5.1 Mbps, downlink: 10.3Mbps, NA: Cat 4, uplink: 50 Mbps, downlink:150 Mbps, JP: Cat 4, uplink: 50 Mbps, downlink:150 Mbps
• SIM Card TypeNano SIM

• Image
• Image SettingsSaturation,brightness,contrast,sharpness,white balance
• Day/Night SwitchDay,Night,Auto,Schedule
• Image EnhancementBLC,HLC,3D DNR
• Wide Dynamic Range (WDR)Digital WDR

• Interface
• On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Built-in Microphone1 built-in microphone
• Built-in Speaker1 built-in speaker
• Reset KeyYes

• Event
• Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle))
• LinkageUpload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,audible warning

• General
• Power12 V, 0.75 A
• MaterialPlastic
• Dimension208 mm × 131 mm × 282.7 mm (8.2" × 7.0" × 11.1")
• Package Dimension386 mm × 201 mm × 225 mm (15.2" × 7.9" × 8.9")
• Approx. 850 g (1.9 lb.)
• With Package WeightApprox. 5400 g (11.9 lb.)
• General FunctionMirror,flash log
• Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions0 °C to 50 °C (32 °F to 122 °F). Humidity 95% or less (non-condensing)

• Battery
• Battery TypeLithium
• Battery VoltageDC 6 V to DC 8.4 V
• Capacity9000 mAh (3.7 V)
• Max. Charging Voltage8.4 V
• Max. Output Voltage8.4 V
• Operating Temperature

  Charging: 0 °C to 45 °C (32 °F to 113 °F)

  Discharging: -20 °C to 55 °C (-4 °F to 131 °F)

• Battery LifeMore than 800 cycles

• Approval
• RF

  CE-RED: EN 301489-1 V2.1.1 (BT or 2.4G), EN 301489-17 V3.1.1 (BT or 2.4G), EN 300328 V2.1.1 (BT or 2.4G), EN 62311: 2008 (BT or 2.4G)

  *CE certification is only for the device sold in the European region.

• EMC

  CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

  IC: ICES-003: Issue 7,

  KC: KN32: 2015, KN35: 2015

• Safety

  CB: IEC 62368-1: 2014+A11,

  CE-LVD: EN 62368-1: 2014/A11: 2017,

  BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Environment

  CE-RoHS: 2011/65/EU,

  WEEE: 2012/19/EU,

  Reach: Regulation (EC) No 1907/2006

• ProtectionIP66: IEC 60529-2013
