Specifications:

• Video and Audio
• IP Video Input4-ch
• Incoming Bandwidth20 Mbps
• Outgoing Bandwidth20 Mbps

• Decoding
• Stream TypeVideo, Video & Audio
• Recording Resolution6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

• Network
• Network Interface1, RJ-45 10/100 Mbps self-adaptive Ethernet interface

• Wireless Parameter
• Frequency Band2.4 GHz
• Antenna StructureHigh gain antenna
• Transmission Speed150 Mbps

• Auxiliary Interface
• SD Card32G/64G/128G/256G/512G

• General
• Power Supply12 VDC, 1 A
• Consumption≤ 6 W
• Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity10 to 90 %
• Dimension (W × D × H)163 x 125 x 26 mm (6.4" × 4.9" × 1.0")
• ≤ 500 g

• Others
• RESET buttonSupport
• Online Indicator

  Solid on: Network is connected;

  Solid off: Network is disconnected or network exception occurs

• Power Indicator

  Solid on: Device is powered up;

  Solid off: Device is powered off or power supply exception occurs;

  Flickering: Device is being restored

• SD Card Indicator

  Solid on: SD card is detected;

  Solid off: No SD card is detected;

  Flickering: There is data transmission

• Wi-Fi Indicator

  Solid on: Wi-Fi is initializing or there is no data transmission through Wi-Fi;

  Solid off: Wi-Fi exception occurs;

  Flickering slowly (on for 2 sec and off for 2 sec ): Wi-Fi is initialized and there is data transmission through Wi-Fi
