Specifications:

• Software features
• Zones64 (8 On-board zones, max 8 wired PIRCAM)
• Area32
• User

  Installer: 1

  Administrator: 1

  Operator: 62

• SMS notificationSupport (with GPRS/3G/4G module)
• Onboard video clips4
• ARC protocol

  ISAPI: Supports iVMS-4200 client software and web client

  Cloud P2P: Supports cloud P2P privacy protocol

  DC-09: ARC accessible（ADM-CID/SIA-DCS ）

  CSV-IP: Supports CSV-IP

  ISUP: Supports ISUP 5.0

• Programming toolsWeb/iVMS-4200/Hik-Partner Pro/Keypad
• Firmware upgradeWeb/iVMS-4200/Hik-ProConnect/Hik-Partner Pro
• End of Line ResistanceSupport 1K, 2.2K, 4.7K, 5.6K, 6.8K, 8.2K

• Hardware features
• Alarm input64 (Including 8 on-board zones)
• Alarm output64 (Including 2 on-board relay outputs and 2 on-board I/O outputs)
• Power Output

  1. Bell：maximum 12V 1.2A

  2. AUX：maximum 12V 1.5A

• 3/4G on boardOptional
• GPRS on boardOptional
• Wi-Fi802.11b/g/n (2.4GHz)
• Bus1 Speed-X bus
• Sounder output1 Wired on-board sounder output
• Tamper-Proof

  1 switch to detect removal from mounting

  1 switch to detect front cover open

• Netowrk interface1 RJ45 10M/100M Ethernet interface

• Display
• Indicator

  4 On-board LEDs:

  ① 1 AC power LED indicator (Green)

  ② 1 System status LED indicator (Green/Red)

  ③ 1 PSTN status LED indicator (Green/Red)

  ④ 1 Mobile communication status LED indicator (Green/Red)

• Electrical characteristics
• Power interface100 to 240 VAC（on-board power transformer）
• Power Consumption

  1. 220V power supply

  ① With an alarm: 2A, 32W

  ② Without an alarm: 250mA, 4W

  2. 13.5V battery supply

  ① With an alarm: 1.7A, 25W

  ② Without an alarm: 200mA, 2.7W

• Battery typeLead acid battery (12V 7Ah, battery is not included by default)
• Battery life spanUp to 36hrs

• General
• Operation temperature-10°C to 40°C
• Operation humidity10% to 90%
• Shell materialPlastic
• ColorWhite
• Dimension(WxHxD)261 mm × 199 mm × 86.4 mm
• 997 g

• Device management
• Tag64
• Keyfob64
• Keypad8
• Wireless sounder16
