Specifications:

• Door station/System parameters
• Operation systemLINUX
• Flash32 MB
• RAM256MB

• Door station/Video parameters
• Camera2MP HD camera
• Night visionLow illumination IR supplement mode:2.5m
• Backlight compensationSupport
• Digital noise reductionSupport
• WDRTrue WDR
• Field of viewHorizontal: 129° Vertical: 75°
• Video Compression StandardH.264; H.265; MJPEG
• Stream

  PAL：Main stream: 1080p@25fps, 720p@25fps Sub stream: 720p@25fps，480p@25fps

  NTSC：Main stream: 1080p@30fps, 720p@30fps Sub stream: 720p@30fps，480p@30fps

• Motion detectionSupport
• Flash-avoid frequency50 Hz, 60 Hz

• Door station/Audio parameters
• Audio input1 built-in omnidirectional microphone
• Audio output1 built-in loudspeaker
• Audio qualityNoise suppression and echo cancellation
• Audio compression standardG711U、G711A、G726、AAC_LC、AAC_LD、OPUS、G722.1
• Audio compression Rate16/32/64 Kbps
• Audio intercomTwo-way audio communication

• Door station/Network parameters
• Network protocolTCP/IP, RTSP, IPV6, ONVIF
• Wi-Fi2.4GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n

• Door station/Device interfaces
• Network interface1 RJ-45, 10/100 Mbps self-adaptive
• RS-4851
• Alarm input4
• Lock control1 relay, Max. 30 VDC 2 A
• Door contact input1
• TAMPER1
• Audio output1 external loudspeaker(Reversed)

• Door station/General
• Power consumption＜ 10 W
• Working temperature-40° C to 53° C(-40° F to 127.4° F)
• Working humidity10% to 95%
• Dimension181.6 mm × 103.6 mm × 29.5 mm
• InstallationSurface mounting, Flush mounting
• Protection levelIP65
• Indicator2
• Power supply

  IEEE802.3af, standard PoE

  12 VDC

• Indoor station/System parameters
• Operation systemLinux
• Memory128 MB
• Flash32 MB

• Indoor station/Display parameters
• Display screen7-inch colorful TFT screen
• Display resolution1024 × 600
• Operation methodCapacitive touch screen

• Indoor station/Audio parameters
• Audio input1 built-in omnidirectional microphone
• Audio output1 built-in loudspeaker
• Audio qualityNoise suppression and echo cancellation
• Audio compression standardG.711 U
• Audio compression Rate64 Kbps

• Indoor station/Network parameters
• Wired network1 RJ-45, 10/100 Mbps self-adaptive
• Wireless network2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
• ProtocolTCP/IP, SIP, RTSP

• Indoor station/Device interfaces
• RS-4851 RS-485 (Half duplex)
• Alarm input8-ch alarm inputs
• Relay output2
• TF cardSupport TF card, up to 128 G

• Indoor station/General
• Power consumption≤ 5 W
• Power supply12 VDC, 1 A,IEEE802.3af, Standard PoE
• Working temperature-10 °C to 50 °C (14 °F to 122 °F)
• Working humidity10% to 90%
• Dimension (L x W x H)175 mm × 113.5 mm × 21 mm (6.9" × 4.5" × 0.83")
