Specifications:

• Power Supply/General
• ModelDS-K7M-AW24
• Power supply

  Power input: 110 to 230 VAC

  Power output: 12 VDC, 24 W

• Power consumption

  Power output: 24 W

  Momentary current: 5 A

  Persistent current: 2 A

• Working temperature-10 °C to 50 °C (14 °F to 122 °F)
• Working humidity＜ 95%
• Dimensions168 mm × 216 mm × 73.3 mm

• Magnetic Lock/General
• ModelDS-K4H255S
• Maximum holding forceMax. 272 kg (600 Lbs)
• Power supply12 VDC, 470 mA - 24 VDC, 235 mA
• Working temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working humidity0 to 90% (Relative humidity)
• Dimensions

  Lock Body: L×W×H: 250 mm × 28 mm × 48 mm (9.8" × 1.1\" × 1.9\")

  Armature Plate: L×W×H: 180 mm × 38 mm × 12 mm (7.1 × 1.5\" × 0.5\")"

• Door typeWooden door, glass door, and metal Door
• Shell performanceHard Anodizing electroplating operated
• Lock bodyEco-friendly Zinc electroplating operated
• Armature plateEco-friendly Zinc electroplating operated

• Bracket of Magnetic Lock/General
• ModelDS-K4H255-LZ
• Dimensions

  L-bracket Dimension (L×W×H): 250×46×30mm (9.8×1.8×1.2");

  Z-bracket Dimension (L×W×H): 180×47×47mm (7.1×1.9×1.9)"

• Suitable DoorWooden door, glass door, and metal door
• Shell performanceHigh strength aluminum alloy surface sandblasting oxidation

• Exit Button/General
• ModelDS-K7P07
• Power supply12 to 24 VDC
• Working temperature-20 °C to 55 °C (-4 °F to 131 °F)
• Working humidity0 to 95% (Relative humidity)
• Dimensions115 mm × 70 mm × 16 mm (4.53" × 2.76" × 0.63")
• MaterialPanel: stainless steel
