Specifications:

Performance

• MIMO
• 6 GHz
• 2 x 2 (DL/UL MU-MIMO)
• 5 GHz
• 4 x 4 (DL/UL MU-MIMO)
• 2.4 GHz
• 2 x 2 (DL/UL MU-MIMO)
• Max. Data Rate
• 6 GHz
• 5.8 Gbps (BW320)
• 5 GHz
• 8.6 Gbps (BW240)
• 2.4 GHz
• 688 Mbps (BW40)
• Antenna Gain
• 6 GHz
• 6 dBi
• 5 GHz
• 6 dBi
• 2.4 GHz
• 4 dBi
• Max. TX Power
• 6 GHz
• 24 dBm
• 5 GHz
• 29 dBm
• 2.4 GHz
• 23 dBm
• Max. BSSIDs
• 8 per Radio
• Supported Data Rates
• 802.11be (WiFi 7)
• 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) 5 GHz: 7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)
• 802.11ax (WiFi 6)
• 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
• 802.11ac (WiFi 5)
• 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
• 802.11n
• 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)

Features

• Wireless Meshing: Yes
• Band Steering: Yes
• 802.11v BSS Transition Management: Yes
• 802.11r Fast Roaming: Yes
• 802.11k Radio Resource Management (RRM): Yes
• Zero-Wait DFS: Yes
• Advanced Radio Management: Yes
• Real-Time Spectral Analysis: Yes
• Passpoint (Hotspot 2.0) :Yes
• Captive Hotspot Portal
• Custom Branding Landing Page: Yes
• Voucher Authentication: Yes
• Payment-Based Authentication: Yes
• External Portal Server Support: Yes
• Password Authentication: Yes
• Guest Network Isolation: Yes
• Private Pre-Shared Key (PPSK): Yes
• WiFi Speed Limiting: Yes
• Client Device Isolation: Yes
• WiFi Schedules :Yes
• RADIUS over TLS (RadSec) :Yes
• Dynamic RADIUS-assigned VLAN: Yes

Hardware

• Max. Power Consumption
• 29W
• Supported Voltage Range
• 42.5—57V DC
• Networking Interface
• (1) 10 GbE RJ45 port
• Weight
• 800 g (1.8 lb)
• Management
• Ethernet
• Enclosure Material
• UV-stabilized polycarbonate, aluminum alloy
• Mount Material
• Stainless steel (SUS304), galvanized steel (SGCC)
• LEDs
• System
• White/Blue
• Channel Bandwidth
• HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
• Certifications
• CE, FCC, IC
• NDAA Compliant: Yes
• Ambient Operating Temperature
• -30 to 40° C (-22 to 104° F)
• Ambient Operating Humidity
• 5 to 95% noncondensing

Software

• Application Requirements
• UniFi Network
• Version 9.0.114 and later
